IMO ISOLATORS
A range of IMO isolators, designed to isolate your electrical circuit safely.
Features
- On Load 10A - 125A (AC21)
- Up to 3 padlock positions
- Range includes various mounting options, Changeover switches and accessories
- Enclosed and panel mounted options shown below
- UL Approved
| Part Number | Description | Data Sheets |
|---|---|---|
| BIS1063A | 1 POLE 63A | Download |
| BIS2063A | 2 POLE 63A | Download |
| BIS2100C | 2 POLE 100A | Download |
| BIS2125A | 2 POLE 125A | Download |
| BIS3063A | 3 POLE 63A | Download |
| BIS3125A | 3 POLE 125A | Download |
| BIS4063A | 4 POLE 63A | Download |
| BIS4100C | 4 POLE 100A | Download |
| BIS4125A | 4 POLE 125A | Download |
| PE69-4020 | 4 POLE ENCLOSED ISOLATOR 20A | Download |
| PE69-4025 | 4 POLE ENCLOSED ISOLATOR 25A | Download |
| PE69-4032 | 4 POLE ENCLOSED ISOLATOR 32A | Download |
| PE69-4040 | 4 POLE ENCLOSED ISOLATOR 40A | Download |
| LB69-4020 | 4 Pole Base Mount Interlock Isolator 20A | Download |
| LB69-4025 | 4 Pole Base Mount Interlock Isolator 25A | Download |
| LB69-4032 | 4 Pole Base Mount Interlock Isolator 32A | Download |
| LB69-4063 | 4 Pole Base Mount Interlock Isolator 63A | Download |
| LB69-4080 | 4 Pole Base Mount Interlock Isolator 80A | Download |
| LB69-40100 | 4 Pole Base Mount Interlock Isolator 100A | Download |
| LB69-40125 | 4 Pole Base Mount Interlock Isolator 125A | Download |
| H69-0001 | Rotary Isolator Handle | Download |
| H69-0003 | Isolator Handle | Download |
| E69-0001 | 100mm Extension Shaft | Download |
| E69-0002 | 200mm Extension Shaft | Download |
| E69-0003 | 300mm Extension Shaft | Download |
| E69-0004 | 400mm Extension Shaft | Download |
